Telwin MMA Welding Machine 230V ACX – TECHNOLOGY 238 XT CE/MPGE + CASE

MMA and TIG inverter, electrode welding machine in direct current (DC) with scratch striking. Use with a wide range of electrodes: rutile, basic, stainless steel, cast iron, cellulosic, etc. Recommended for motor-generators, this model grants high performance despite power supply instability, thanks to the MPGE multiprotection: control device of the waveform, filter against input peaks, stabilization of oscillations. Robust and impact resistant.

Features:
– Compact and light
– 50 dense
– high welding current stability in spite of mains voltage fluctuations
– regulation of arc force and hot start according to the type of electrode in use
– anti-stick device
– thermostatic, overvoltage, under-voltage, overcurrent protections.
Complete with MMA welding accessories and aluminum carry case.

Specifications:

• ABSORBED POWER AT 60%3 kW
• SINGLE PHASE MAINS VOLTAGE230 V
• MOTORGENERATOR MINIMUM POWER10 kW
• MAINS FREQUENCY50 / 60 Hz
• EFFICIENCY87 %
• CURRENT RANGE5 200 A
• POWER FACTOR (cosphi)0,7
• MAX CURRENT DC (EN 60974-1)200 @ 35 % A
• D. USABLE ELECTRODES IN DC1,6 4 mm
• DC CURRENT140 A
• PROTECTION DEGREEIP23
• MAX NO LOAD VOLTAGE80 V
• MAX ABSORBED CURRENT39 A
• ABSORBED CURRENT AT 60% MAX20 A
• MAX ABSORBED POWER6,3 kW
